QARSHYGA T-5
Reconnaissance and tactical aerial complex
A five-metre combustion-engine aircraft: 9–12 hours of flight and a 10 kg payload.
- 9–12
- hours aloft
- 5 m
- wingspan
- 10 kg
- payload
- 60 km
- telemetry radius
The company’s largest unmanned programme. Unlike the electric platforms, this aircraft uses a combustion engine: its fuel load supports 9 to 12 hours in the air — the endurance needed for long-range patrol and wide-area surveillance.
The aircraft has a starter, a generator and an automatic flight-control system, and takes off from and lands on a 200 m strip. Its 10 kg payload capacity accommodates any applicable sensor suite.
Applications
- Long-duration aerial patrol
- Border and wide-area surveillance
- Early wildfire detection
- Relay and communications
Technical specifications
| Parameter | Value |
|---|---|
| Dry weight | 20 kg |
| Fuel weight | 6 kg |
| Payload weight | 10 kg |
| Wingspan | 5,000 mm |
| Fuselage length | 2,400 mm |
| Engine type | Internal combustion |
| Starter | Fitted |
| Generator | Fitted |
| Fuel | Petrol (AI-95) |
| Control system | Automatic |
| Take-off | from a 200 m runway |
| Landing | onto a 200 m runway |
| Endurance | 9–12 hours |
| Telemetry link radius | 60 km |
| Payload type | Any applicable |
Gallery
QARSHYGA T-5
